Friday, 1 February 2019

Stud.io v2.0 and Eyesight Photo Real Renderer

I've had a quick look at the "Photo Real" renderer that Stud.io v2.0 uses - its called Eyesight and there are some reports that it's based on Blender's "Cycles" renderer but I can't be certain of that.

Eyesight seems to be a command line renderer so you throw commands at it and it renders something.  Here's the command that Stud.io creates when you click the render button

"C:\Program Files\Studio 2.0\PhotoRealisticRenderer\win\64\eyesight.exe" --daewindingorder clockwise --autoexit --device-occupation 5 --device CPU --logpath C:\pathToMyFile\logFile.log --width 640 --height 480 --samples 256 --ground --ground-red 0.8 --ground-green 0.8 --ground-blue 0.8 --defaultlight --preset BUILD_RL --defaultlight-rotz 29.58608 --light-intensity 1 --daefile C:\pathToMyFile\myFile.dae --output C:\pathToMyFile\myFile.png

Stud.io wrties the .dae file to this location (or you can just use export>dae from the file menu)

C:\Users\[yourUsername]\AppData\Local\Temp\Studio

The .dae file that Stud.io creates for Eyesight to render is a txt file based on Collada's .dae XML file format (so you can just edit it with a text editor) - this gives you access to all the "internal" render parameters.  Stud.io also lets you add scratches to the render which is unusal - I've over-cooked the scratches on this model to make it obvious!



The scratches are configured in the .dae XML file and use some preset textures that are stored here...

C:\Program Files\Studio 2.0\PhotoRealisticRenderer\win\64\textures

So you could in theory make you own scratches - plus there is also a Lens dirt texture in there but I can't see how to apply that in Stud.io.

Typing

"C:\Program Files\Studio 2.0\PhotoRealisticRenderer\win\64\eyesight.exe" --help

will give you Eyesignt's command line help



There are some interesting options there - particularly the "animation" ones.

Sunday, 6 January 2019

Creating Lego Instructions From The Command Line

As Brickalo (www.brickalo.com) now allows a computer to create multiple ldr files I wondered if it was possible to also create LEGO instructions, as PDF files,automatically from the command line.  Whilst the computer doesn't need any instructions they are still useful for us humans when physically building Lego models! After a bit of poking around I discovered it was possible to use the command line with the latest version of LPub3D v2.3.3

You can use the following command

"C:\Program Files\LPub3D\LPub3D.exe" -pe -o -f "C:\path\myFile.ldr"

Which will output a pdf file in the same folder as the ldr file (and with the same name - just with .pdf on the end) - The full list of command line options for LPub3D is here..

https://github.com/trevorsandy/lpub3d/issues/12

Sunday, 16 December 2018

Binvox 2 LDR (Part 3)

So here's my binvox to ldr converter with brick optimistation and layer rotation (to add strength to the resulting model).  You need python 2.7 and numpy installed - unzip the archive and it should run from the resulting folder - there is a binvox file (moo.binvox) for testing which the code will use by default and the binvox rw file (which my code calls to read the binvox binary).

https://drive.google.com/file/d/1ypVxLItw2attg6j1iMsJdyPzdEVRDDYk/view?usp=sharing

You can use it using the following line in the cmd window

"C:\path\binvox2ldr.py" "C:\path\myfile.binvox"

Here's what you should end up with if you run the code without your own binvox file - the code also adds a STEP for each layer of the model.


Currently all the output is grey - coloured bricks will require an alternative solution as binvox does not support colour (that I can access anyway) - I'm looking a Goxel, which I think should work (http://guillaumechereau.github.io/goxel/) but it will probably be the New Year before I get back to this now.

If you are making your own binvox files (from .obj's) I sugest using the:  -d 32 -rotx parameters during the conversions as this makes a relatively small model and rotates the obj so the bricks are pointing upwards (well it works for me anyway!)

Here are some more of my model conversions....



Tuesday, 11 December 2018

Binvox 2 LDR (Part 2)

Using the binvox python parser allows relatively easy access to each voxel layer slice in the binvox file - once a voxel slice is transferred to a numpy matrix it's then possible to translate each voxel into a single 1x1 Lego brick...



I've included the code to do this here but as I've noted previously a 1x1 brick model isn't much good if you want to actually build a physical representation of the 3D object in question - you need to optimise the voxel matrix for each slice of the model into larger bricks;  and there is a Perl script to do just that here.  This Perl script optimises the voxel slice grouping individual voxels into larger Lego bricks - Exactly what I needed to do in a python script!

One of the disadvantages of this Perl script is that it does not add a strengthening element for each layer in the voxel matrix (so each layer is simply build on the layer below often using similar bricks) which is something that had been raised at London AFOLs, consequently I thought it would be good to try to add some strength to model by rotating each layer at 90 degree's to each other during the translation of voxels to bricks - this would automatically add a degree of strength to any subsequent build.  The other disadvantage with the Perl script is that you have to go through an intermediary text file before you can process the binvox file - it's not a major problem but it would be nice to try to get everything done in one go from binvox to LDR.

Saturday, 1 December 2018

Binvox 2 LDR (Part 1)

Following a discussion at our last London AFOL meetup, I've taken a slight diversion to look at creating ldr files from binvox files - Binvox is a small program that voxelises 3D files (like .obj) into a voxel model.  Binvox is a good solution for transferring 3D models into games like Minecraft and I used it a while back to help create a simple animation system in Minecraft (a long time ago!)



Binvox to Minecraft translation is relatively straight-forwards as nearly all Minecraft's main components can be considered as a single voxel element.

Binvox to Lego presents an additional challenge as Lego doesn't really work if you translate each voxel to 1x1 brick as the resulting physical model (if you tried to build it) will simply fall apart.  There is already a mechanism to go from Binvox to Ldr here using a Perl script.  This script is a two stage process requiring you to convert the binvox file to a txt file so that Perl can parse the txt file but this Perl script adds an important element for Lego in that it optimises the voxel matrix for each layer into larger Lego bricks, so that you are not simply building with 1x1 bricks.

This Perl scripts works (and is probably one of the easiest Perl scripts to read that I've ever encountered!) but I wanted to see if I could bypass the requirement to translate the binvox file to txt and also add some strength to the model by rotating layers at right angles to each other.  I also wanted to code it in Python, as my Perl is rustier that a rusty nail that has been left in a jar of salt water for 10 years (which is also how long it's been since I've written any Perl!).

My starting point was this Binvox python parser which would take the hard work out of having to deconstruct structure of the binvox file.  With this is should be relatively easy to convert Binvox direct into LDR files...


Monday, 5 November 2018

Brickalo - Modo Command Line file

A number of people have asked about using MODO command line to render LDraw .ldr files.  Links to Modo and the LDR importer for MODO are in the footer of the Brickalo site.  Modo is a free 30 day download from The Foundry - MODO_CL (Modo command line) will continue to work after the 30 day trial expires.  The LDR importer for Modo is donationware (and well worth a donation!).

My previous posts about using Modo are here...
https://cultofthebrick.blogspot.com/2018/03/modo-and-ldraw-part-1.html
https://cultofthebrick.blogspot.com/2018/03/modo-and-ldraw-part-2.html
https://cultofthebrick.blogspot.com/2018/03/modo-and-ldraw-part-3.html

I'm primarily using Windows but the principle should work on a Mac (but you will need to change the paths) - as far as I'm aware there is no LDraw>Modo plugin for Linux.

I've included the command line script below - or you can download the zip file containing the script and sample brickalo ldr file from here

To execute the command line in a cmd window your command line should look something like this...



Command line documentation for MODO can be hard to find and this may not be the best way to implement ldr rendering but it works for my requirements.  Remember that the camera placement noted in this script moves the camera to frame a Rainbow Lego Tower on Brickalo - for your model it will be different!   Also the camera target (where the camera looks at) will also likely be different.  I found controlling the camera framing and the camera target using ModoCL hard - I've spent quite a bit of time trying to convert a POVray camera to a Modo camera but to date I've not succeeded working out the maths to do the conversion reliably.

Create a "brickalo" folder in your home directory then either download the zip file above or create a file called brickalo.txt and copy and paste the code below (and you'll need your own myLegoFile.ldr too)...

#======================================================================================================================================
# BRICKALO MODO RENDER BY NEIL MARSDEN 2018
#Make sure both MODO and the LDRAW Plugin for Modo is installed
#Currently an LDRAW folder needs to be in C:\LDRAW Modo_CL does not see the LDRAW location set for the plugin in Modo
#But you still need to load the config file so that Modo_CL knows where the LDRAW plug-in is

#In the comand window copy and paste the following line - BUT MAKE SURE YOU CHANGE UserName to your UserName so mine would be "C:\Users\Neil\brickalo\brickalo.txt"
#"C:\Program Files\Foundry\Modo\11.2v2\modo_cl.exe" -config "C:\Users\UserName\AppData\Roaming\Luxology\MODO11.2.CFG" < "C:\Users\UserName\brickalo\brickalo.txt"

#Lots of people have this at the start of their modo scripts!
log.toConsole true
log.toConsoleRolling true
#=========  Open LDR File ==========
scene.open "C:\Users\UserName\brickalo\myLegoFile.ldr"
#=========  Move the Camera ==========
camera.transformTo Camera -0.228601471 1.172085693 -0.844499451 0 0 0
#========= Create Mesh - this will be the camera target ==========
item.create mesh
item.name "cameraTarget"
transform.channel pos.X 0
transform.channel pos.Y 0.175
transform.channel pos.Z 0
#========= Target Camera ==========
#Select the Camera then the Mesh then point the camera at the Mesh
select.subItem Camera set
select.subItem cameraTarget add
target set
#Changes the field of view (zoom)
camera.hfov 22
#========= Start Image Render ==========
select.Item Render
item.channel step 1
item.channel first 1
item.channel last 1
item.channel outPat "_<FFFF>"
#========= Render HD Landscape Resolution ==========
render.res 0 1920
render.res 1 1080
#========= Output the images BUT MAKE SURE YOU CHANGE UserName to your UserName! ==========
render.animation "C:\Users\UserName\brickalo\OutputImage" PNG
#========== Or render a turnaround animation - rem out the previous line and use this next line instead (remove the hashtag) - BUT MAKE SURE YOU CHANGE UserName to your UserName! ==========
#render.turntable "C:\Users\UserName\brickalo\OutputMovie.mp4" pyFFMPEGMP4 24 12.0 0
#WORKS?!

Sunday, 4 November 2018

Playing Lego With Python - www.brickalo.com

So I've taken a break from developing the python code for tracking and adding Lego bricks to an .ldr model file so that I could turn my current code into a website which would help to display some of the ideas that I've been working on.   The result is www.brickalo.com



I've tweaked the colour allocation of bricks so that it creates a "rainbow" effect as the bricks are added to the pile and I've used some of the other work I've done in Modo to create a command line renderer for each Lego pile so that you end up with a pretty picture of your pile of Lego - I used Mobirise to create the basic bootstrap website - Mobirise is free and allows you to create a static bootstrap website really quickly and easily but I then had to switch to PHP to create the dynamic code for the website (the "WOW BRICKALO" gallery section on the home page and the timeline elements on the Archive page).  Working in PHP was slightly weird having spent so long in Python, but the main structures are similar so coding the dynamic elements was not too complex.




The whole site is hosted on Amazon's AWS free tier and whilst in isolation www.brickalo.com might seem a bit weird; as a method of displaying the work I've done - mostly on my commute to and from work over the last nine months, I feel it works well and I'm really pleased that it's drawn together a number of different strands that I've been working on over the last year.
